description
Spare parts for the body, basket and chassis of your Manitou aerial work platform can be found here.
Filter
Product.Nr.: 24433633
| Ø steering connection |
30 |
| Bolzen |
4 x M14 1,5 mm |
| Ø Nabe (mm) |
150 |
Product.Nr.: 24433634
| Ø steering connection |
30 |
| Bolzen |
4 x M14 1,5 mm |
| Ø Nabe (mm) |
150 |
Product.Nr.: 24433632
| Einbau-Ø (mm) |
10 |
| Resitance (Ω) |
11 |
| Länge Kabel (mm) |
390 |
| Anzahl Verbindungen |
3 |
Product.Nr.: 24433619
| Material |
Steel |
| Abmessungen außen (mm) |
105 x 35 |
| Abmessungen innen (mm) |
89 x 25 |
Product.Nr.: 24433620
| Material |
Steel |
| Abmessungen außen (mm) |
119,5 x 35 |
| Abmessungen innen (mm) |
103,5 x 26,5 |
Product.Nr.: 24433621
| Material |
Steel |
| Abmessungen außen (mm) |
96 x 50 |
| Abmessungen innen (mm) |
75 x 36 |
Product.Nr.: 24433622
| Material |
Steel |
| Abmessungen außen (mm) |
97,5 x 50 |
| Abmessungen innen (mm) |
75 x 37 |
Product.Nr.: 24433624
| Material |
Steel |
| Abmessungen außen (mm) |
120 x 58 |
| Abmessungen innen (mm) |
118 x 58 |
Product.Nr.: 24433625
| Material |
Steel |
| Abmessungen außen (mm) |
119,5 x 35 |
| Abmessungen innen (mm) |
103,5 x 26,5 |
| Bild | Art.Nr. | Artikelname | Height (mm) | Width (mm) | Lenght (mm) | Ø Loch (mm) | Thread | Ø steering connection | Bolzen | Ø Nabe (mm) | Einbau-Ø (mm) | Resitance (Ω) | Länge Kabel (mm) | Anzahl Verbindungen | Material | Abmessungen außen (mm) | Abmessungen innen (mm) | Diameter (mm) | Preis | Anzahl | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
24433630 | Base plate Safety cage |
42 |
736 |
920 |
||||||||||||||||
 |
24433628 | Handle |
64 |
122 |
|||||||||||||||||
 |
24433629 | Handle |
24 |
139 |
6,5 |
||||||||||||||||
 |
24433631 | Lever |
156 |
M8 x 1,25 mm |
|||||||||||||||||
 |
24433626 | Chain link set |
94 |
140 |
|||||||||||||||||
 |
24433633 | Steering axle incl. hub, bolt, bearing |
30 |
4 x M14 1,5 mm |
150 |
||||||||||||||||
 |
24433634 | Steering axle incl. hub, bolt, bearing |
30 |
4 x M14 1,5 mm |
150 |
||||||||||||||||
 |
24433632 | Potentiometer |
10 |
11 |
390 |
3 |
|||||||||||||||
 |
24433619 | Drag chain |
Steel |
105 x 35 |
89 x 25 |
||||||||||||||||
 |
24433620 | Drag chain |
Steel |
119,5 x 35 |
103,5 x 26,5 |
||||||||||||||||
 |
24433621 | Drag chain |
Steel |
96 x 50 |
75 x 36 |
||||||||||||||||
 |
24433622 | Drag chain |
Steel |
97,5 x 50 |
75 x 37 |
||||||||||||||||
 |
24433623 | Drag chain rep. connector | |||||||||||||||||||
 |
24433624 | Drag chain link |
Steel |
120 x 58 |
118 x 58 |
||||||||||||||||
 |
24433625 | Drag chain link |
Steel |
119,5 x 35 |
103,5 x 26,5 |
||||||||||||||||
 |
24433635 | Tie rod |
525 |
37 |
|||||||||||||||||
 |
24433618 | Bar for safety cage |
762 |
30 |
|||||||||||||||||
 |
24433627 | Door handle |
45 |
127 |
