Name: Axle Zsb. right
Brand: TVH
SKU: 24434048
Availability: InStock

Filter

for areal platform lifts

Height (mm)

max. Länge oben (mm)

Max .Ø Innen (mm)

Diameter (mm)

Width (mm)

Länge gesamt (mm)

Thread

Ø Außen (mm)

Ø Innen (mm)

Länge Hülle (mm)

Type

Ø max. (mm)

Ø Loch (mm)

Product.Nr.: 24434048

Axle Zsb. right

for areal platform lifts

120T

Product.Nr.: 24434062

Bellows

for areal platform lifts	210 120T 120H(TM34H) 170
Height (mm)	125
max. Länge oben (mm)	62
Max .Ø Innen (mm)	55

Product.Nr.: 24434063

Bellows

for areal platform lifts	210 120T SD170 170
Height (mm)	30
max. Länge oben (mm)	9
Max .Ø Innen (mm)	21

Product.Nr.: 24434049

Chassis part

for areal platform lifts

120
120T
120H
170

Product.Nr.: 24434050

Chassis part

for areal platform lifts	120H 120T TD120TN
Height (mm)	37
Diameter (mm)	200

Product.Nr.: 24434051

Chassis part

for areal platform lifts	HR15N/17N HR15/17 HR10/HR12
Width (mm)	65
Länge gesamt (mm)	455

Product.Nr.: 24434053

Joint set

for areal platform lifts

210
120T
120H(TM34H)
HR10
SD170
170

Product.Nr.: 24434052

Ball joint

Länge gesamt (mm)	27
Thread	Innengewinde M5/M6 RH

Product.Nr.: 24434054

Ball joint

for areal platform lifts	HR21, 210
Height (mm)	25
Ø Außen (mm)	16
Ø Innen (mm)	5

Product.Nr.: 24434060

Ball screw drive

for areal platform lifts	170/TM50 SD170/SD50 HR12 120H(TM34H) HR10DC 210 HR21 210SD
Länge gesamt (mm)	315 550

Product.Nr.: 24434061

Parking brake

for areal platform lifts	120 170
Länge gesamt (mm)	515

Product.Nr.: 24434064

Steel cable

for areal platform lifts	210 120H(TM34H) HR10_DC 120T 170/TM50 HR12 HR10 HR21 SD170 210SD 170
Diameter (mm)	3
Länge gesamt (mm)	1070

Product.Nr.: 24434055

Rod end without bearing

for areal platform lifts	HR12 HR10 SD170
Diameter (mm)	28
Width (mm)	20,3
Thread	M20, 1,5 Pi, RH

Product.Nr.: 24434065

Control cable

for areal platform lifts	HR12
Diameter (mm)	3,5
Länge gesamt (mm)	1460
Länge Hülle (mm)	1285

Product.Nr.: 24434066

Control cable

for areal platform lifts	TL38 TL33
Diameter (mm)	3,6
Länge gesamt (mm)	1445
Länge Hülle (mm)	1280

Product.Nr.: 24434067

Control cable

Diameter (mm)	3,5
Länge gesamt (mm)	3260
Länge Hülle (mm)	3075

Product.Nr.: 24434056

Support wheel

for areal platform lifts	20T 120H(TM34H) 170
Länge gesamt (mm)	650
Type	Einzelrad

Product.Nr.: 24434057

Support wheel

for areal platform lifts	170/TM50 120H(TM34H) 120T
Länge gesamt (mm)	750
Type	Doppelrad

Product.Nr.: 24434058

Support wheel

for areal platform lifts	210 120H(TM34H) 120T 170/TM50 120(TM34) HR12 HR10 SD170 170
Länge gesamt (mm)	550
Type	Einzelrad
Ø max. (mm)	48
Ø Loch (mm)	20,2

Product.Nr.: 24434059

Steering wheel support

for areal platform lifts	210 HR21 210SD
Width (mm)	193
Länge gesamt (mm)	487

Art.Nr.	Artikelname	for areal platform lifts	Height (mm)	max. Länge oben (mm)	Max .Ø Innen (mm)	Diameter (mm)	Width (mm)	Länge gesamt (mm)	Thread	Ø Außen (mm)	Ø Innen (mm)	Länge Hülle (mm)	Type	Ø max. (mm)	Ø Loch (mm)	Preis
24434048	Axle Zsb. right	120T														price
24434062	Bellows	210 120T 120H(TM34H) 170	125	62	55											price
24434063	Bellows	210 120T SD170 170	30	9	21											price
24434049	Chassis part	120 120T 120H 170														price
24434050	Chassis part	120H 120T TD120TN	37			200										price
24434051	Chassis part	HR15N/17N HR15/17 HR10/HR12					65	455								price
24434053	Joint set	210 120T 120H(TM34H) HR10 SD170 170														price
24434052	Ball joint							27	Innengewinde M5/M6 RH							price
24434054	Ball joint	HR21, 210	25							16	5					price
24434060	Ball screw drive	170/TM50 SD170/SD50 HR12 120H(TM34H) HR10DC 210 HR21 210SD						315 550								price
24434061	Parking brake	120 170						515								price
24434064	Steel cable	210 120H(TM34H) HR10_DC 120T 170/TM50 HR12 HR10 HR21 SD170 210SD 170				3		1070								price
24434055	Rod end without bearing	HR12 HR10 SD170				28	20,3		M20, 1,5 Pi, RH							price
24434065	Control cable	HR12				3,5		1460				1285				price
24434066	Control cable	TL38 TL33				3,6		1445				1280				price
24434067	Control cable					3,5		3260				3075				price
24434056	Support wheel	20T 120H(TM34H) 170						650					Einzelrad			price
24434057	Support wheel	170/TM50 120H(TM34H) 120T						750					Doppelrad			price
24434058	Support wheel	210 120H(TM34H) 120T 170/TM50 120(TM34) HR12 HR10 SD170 170						550					Einzelrad	48	20,2	price
24434059	Steering wheel support	210 HR21 210SD					193	487								price
